AirGate 4G GSM Modem Router Modbus Datalogger

Product Specification

Versions	AirGate 4G
Description	AirGate 4G provides following 4G GSM Router : Ethernet >> GSM internet Router Read and record Modbus channels by Rs485 and Ethernet (Modbus Datalogger) Recorded data can send to FTP server in Excel MQTT protocol support SMS alert in case of an alarm in Modbus channels.
GSM Modem	4G
Ethernet GSM Router function	yes
Ethernet	2 x Ethernet (isoleted)
Ethernet Functions	Modbus TCP/IP Client (Master) Ethernet >> internet GSM Router
Serial Port	1 x Rs485 (isolated)
Seri Port	Modbus RTU Master
WiFi	yes
Datalogger Function	Record int SD Card Modbus RTU and Modbus TCP/IP Master MQTT function FTP Client
DI and DO	2 x DI 2 x DO
Power	9...48 Vdc (max 500 mA @12Vdc)
Working Temperature	-35...+60 ºC
Mounting	DIN Rail
Dimension	106x106x40 mm (without antenna)
