MAQ20 Modular Data Acquisition System - Datalogger

Ports :
- Ethernet (communicate with own software and also Modbus TCP/IP server)
- Rs485 (Modbus RTU Slave)
- USB (communicate with own software)

Datalogger function :
- 2GB SD Kart
- Excel or txt formatted record,
- FTP Server

Other :
- Alarms
- PID Control function (independent 32 PID controller)
- OPC Server
- Python API

8 Channels

- T Type Thermocouple (-100...+400 ºC) (model TTC)

- J Type Thermocouple (-100...+760 ºC) (model JTC)

- K Type Thermocouple (-100...+1350 ºC) (model KTC)

- S Type Thermocouple (0...+1750 ºC) (model RSTC)

- R Type Thermocouple (0...+1750 ºC) (model RSTC)

• Isolated channels
• 4 x cold junction temperature measurement in one module
• High accuracy
• Alarms for each channel
• Push socket connection

6 Channel version (RTD31)

2 or 3 wire Pt100
(also 0-5 Kohm ohm input)

5 Channel version (RTD41)

4 wire Pt100 (for very high accurate measurements)

• Isolated channels
• High accuracy
• Alarms for each channel

8 Channels

0-20 mA

4-20 mA

• Accuracy : ±0,035% span
• Resolution : 0,012% span
• Isolated Channels
• High Accuracy
• Alarm for each channel

8 Channels

0-20 mA

4-20 mA

-20...+20 mA

• Accuracy : ±0,035% span
• Resolution : 0,0015% span
• Isolation : Channel to Channel
• High Accuracy
• Alarm for each channel

8 Channels

±50 mV

±100 mV

±250 mV

±1,0 V

±2,0 V

• Accuracy : ±0,035% span
• Resolution : 0,012% span
• Isolated Channels
• High Accuracy
• Alarm for each channel

8 Channels

±5 Vdc

±10 Vdc

±20 Vdc

±40 Vdc

±60 Vdc

• Accuracy : ±0,035% span
• Resolution : 0,012% span
• Isolated Channels
• High Accuracy
• Alarm for each channel

8 Channels

±100 mV (model ISOMV1)

±1 Vdc (model ISOV1)

±10 Vdc (model ISOV2)

±20 Vdc (model ISOV3)

±40 Vdc (model ISOV4)

±60 Vdc (model ISOV5)

• Accuracy : ±0,035% span
• Resolution : 0,0015% span
• Isolated Channels : Channel to Channel izolasyon
• High Accuracy
• Alarm for each channel

4 Channels

• 1/4 Bridge Strain Gage (Quarter)
• 1/2 Bridge Strain Gauge (Half)
• 1/1 Full Bridge Strain Gauge, Load Cell, LVDT (mv/V)

Presice Excitation Voltage Options :

• 2,5 Vdc
• 3,333 Vdc
• 5,0 Vdc
• 10,0 Vdc

Bridge Completation Range : 100 ohm...1 Kohm

• Accuracy : ±0,03% span
• Resolution : 24 Bit
• Isolated Channels
• High Accuracy
• Alarm for each channel
• Push socket connection

Configuration

• Configuration for Dataforth MAQ20 Data Acquisition System, Datalogger solution
• Sensor - channel configuration, alarm entries

Monitoring

• Dashboard Components : Graphic - Numeric - Bar Graph indicators
• Easy design of view
• parameter showing on a picture
• control of MAQ20 output channels

Reporting

• Direct Excel record
• Table format views
