Expert Logger Professional Data Acquisition System - Datalogger
16-32-46 Analog/Digital Channels
Thermocouple - Pt 100 - Load Cell
mV - m - mA - mV/Volt
Data Acquisition via Digital protocols like Modbus RTU or TCP/IP
Modbu RTU (Master or Slave)
Modbus TCP/IP (Client and Server)
Profibus (Slave) - Canbus - OPC UA (HA : Historical Access)
| Versions | Expert Logger 100 | Expert Logger 200 | Expert Logger 300 | Expert Logger 400 |
|---|---|---|---|---|
| Pictures |  |
|
|
|
| Analog Channels | 16 ch | 32 ch | 46 ch | 16 ch |
|---|---|---|---|---|
| Analog Input Types | Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc mV/V, Load Cell, LVDT, pH probu |
Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc mV/V, Load Cell, LVDT, pH probu |
Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc |
Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc mV/V, Load Cell, LVDT, pH probu |
| Analog channel resolution | 24 Bit - high accuracy | 24 Bit - high accuracy | 24 Bit - high accuracy | 24 Bit - high accuracy |
| Isolation between analog channels and power | Yes | Yes | Yes | Yes |
| Analog channel samplig rate (total) | 1000 measurement/second | 2000 measurement/second | 3000 measurement/second | 1000 measurement/second |
| Datalogger Memory | 2GB or 14GB (select one before order) 2GB : 60 million measurement 14 GB : 420 million measurement |
2GB or 14GB (select one before order) 2GB : 60 million measurement 14 GB : 420 million measurement |
2GB or 14GB (select one before order) 2GB : 60 million measurement 14 GB : 420 million measurement |
2GB or 14GB (select one before order) 2GB : 60 million measurement 14 GB : 420 million measurement |
|---|
| Calculation Channels | You can entry all formules for channels came from analog or digital channels at Expert Logger. Calculation results can save in datalogger device. |
|---|---|
| Counter | You can use this function in order to counter for data came from Digital inputs as pulse and analog channels. |
| Linearisation | You can do linearization for analog values correct measurements or more. |
| Working time | Working time function is for measuring of active time of an event. |
| Statistic | With this function you can have the statictical values like min, max, avg or more for an analog value |
| Logic gates | This function gives you to do Logic operations like And, Or, Nand, Nor gates. |
| Limit (Alarm) channel | It is alarm channel creation but with many function. |
| Control Function | Expert Logger has PID control function if required. This gives you very accurate control in process. |
| Pulse Generator | it is pulse generator which you can arrange time and frequence and use your other functions or formules. |
| Other | We presented only a few functions in this table. "Expert Logger" gives you two or three times more function and flexibility than we gave in this list. |
| ProfiSignal 20 - Go | ProfiSignal 20 Go is graphic based monitoring and reporting software. It is ideal for Univercisites, R&D centers. |
|---|---|
| ProfiSignal 20 - Basic |
As additional to "ProfiSignal Go" you can also design pages using powerfull components.
|
| ProfiSignal Klicks |
ProfiSignal Klicks is covering all functions of Basic and additionally give coding flexibility.
|
