DigiRail Connect Modbus IO Modules

RAMIX : AI - AO - DI - DO

DMIX : DI - DO

Communication Specification

Versions	RAMIX-DO-ETH	RAMIX-RL-ETH	DMIX-DO-ETH	DMIX-RL-ETH
Port 1	Rs485	Rs485	Rs485	Rs485
Port 1 Protocol	Modbus RTU Slave	Modbus RTU Slave	Modbus RTU Slave	Modbus RTU Slave

Port 2	Ethernet	Ethernet	Ethernet	Ethernet
Port 2 Protocol	Modbus TCP/IP Server	Modbus TCP/IP Server	Modbus TCP/IP Server	Modbus TCP/IP Server

Port 3	USB for configuration	USB for configuration	USB for configuration	USB for configuration

Other one function	Rs485 Modbus >> Ethernet Converter Function

Power	10...30 Vdc	10...30 Vdc	10...30 Vdc	10...30 Vdc
Mounting	DIN Rail	DIN Rail	DIN Rail	DIN Rail

Input Output specifications

Versions	RAMIX-DO-ETH	RAMIX-RL-ETH	DMIX-DO-ETH	DMIX-RL-ETH
Pictures
Analog Input (AI)	2 ch	2 ch	-	-
Analog Input Options	Pt100, Pt1000 Thermocouple 0-60mV, 0-5 Vdc, 0-10 Vdc 0-20 mA, 4-20 mA	Pt100, Pt1000 Thermocouple 0-60mV, 0-5 Vdc, 0-10 Vdc 0-20 mA, 4-20 mA	-	-
Analog Input Resolution	16 bit	16 bit	-	-

Analog Output (AO)	2 ch	2 ch
Analog Output options	4-20 mA or 0-10 Vdc	4-20 mA or 0-10 Vdc
Analog Output Resolution	12 Bit	12 Bit

Digital Input (DI)	4 ch	4 channel	8 ch.	8 ch

Digital Output (DO)	3 ch	-	8 ch	-

Relay Output	-	2 Relay	-	4 Relay
