Expert Key 28 channels Professional Data Acquisition System
28 Analog Channels
Thermocouple - Pt 100 - mV - mA
Ethernet and USB Outputs
Professional Data Acqusition Software : ProfiSignal
| Versions | Expert Key L | Expert Key C |
|---|---|---|
| Pictures |  |
 |
| Analog Inputs | 28 channels | 28 channels |
|---|---|---|
| Analog Input Types | Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc |
Pt100, Thermocouple, 0/4-20 mA, ±20 mA 0-5 Vdc, 0-10 Vdc, ±10 Vdc |
| Analog Input Resolution | 18 Bit - High Accuracy | 18 Bit - High Accuracy |
| Isolation between analog channels and system power | Yes | Yes |
| Analog Channel Sampling Rate (total) | 10KHz (Analog Signals) | 10KHz (Analog Signals) |
| Digital Inputs (High sampling, Frequence) |
4 channels (3 x 1Mhz - 1 x 250 Hz) |
4 channels (3 x 1Mhz - 1 x 250 Hz) |
- | 1 channel (250 Hz) |
|---|---|---|---|---|
| Digital Outputs (configurable as Input or output) |
4 channels | 4 channels | 1 ch | 24 channels |
| Digital Outputs (DO) | 4 channels | 4 channels | - | - |
| Ethernet Port | Yes | Yes |
|---|---|---|
| USB Port | Yes | Yes |
| ProfiSignal 20 - Go | ProfiSignal 20 Go is graphic based monitoring and reporting software. It is ideal for Univercisites, R&D centers. |
|---|---|
| ProfiSignal 20 - Basic |
As additional to "ProfiSignal Go" you can also design pages using powerfull components.
|
| ProfiSignal Klicks |
ProfiSignal Klicks is covering all functions of Basic and additionally give coding flexibility.
|
