Field Logger 8 channels Universal Datalogger
Pt100 - Thermocouple - 4...20 mA - 0...10 Vdc selectable inputs
Longterm record into SD Card
Rs485 Modbus Master : FieldLogger can read data and record from Modbus RTU Slave devices (64 channels)
Ethernet port : Modbus TCP/IP Server - Email (in case of an alarm) - Web Server - FTP
Relay Output (for local alarm)
| Versions | FieldLogger Basic | FieldLogger Full |
|---|---|---|
| Picture |  |
 |
| Display | No | Yes (2,7" color) |
| Analog Channels | 8 channels | 8 channels |
|---|---|---|
| Analog Input Types | Pt100, Thermocouple, 0/4-20 mA 0-5 Vdc, 0-10 Vdc |
Pt100, Thermocouple, 0/4-20 mA 0-5 Vdc, 0-10 Vdc |
| Resolution | 24 Bit - Isolated from device power | 24 Bit - Isolated from device power |
| Analog Kanal Sampling rate (total) | 1000 measurement/second | 1000 measurement/second |
| Record Rate | 1000 measurement/second (total) |
1000 measurement/second (total) |
|---|---|---|
| Datalogger Memory |
Internal Memory 500.000 records |
SD Card records millions |
| Port 1 |
USB (Memory Stick download of records) |
USB (Memory Stick download of records) |
| Port 2 |
USB (for local PC connection : configuration, data download) |
USB (for local PC connection : configuration, data download) |
| Port 3 | --- |
Ethernet Network Connection : Configuration, Monitoring, Data Download Ethernet's other functions : |
| Port 4 |
Rs485 Modbus RTU Slave |
Rs485 Modbus RTU Master : Read 64 channel Modbus Slave data or Modbus RTU Slave |
| Digital Inputs |
8 channels on-off status |
8 channels on-off status |
|---|---|---|
| Output | 2 Relay output | 2 Relay output |
