N1500FT Flow Indicator - Panelmeter

Specifications

Version	N1500FT
Dimension	48 x 96 Depth : 92 mm

Input 1	Pulse Dry Contact : 0,1-10 Hz Pulse (NPN or PNP) : 0,1-50 KHz
Input 2	4-20 mA
Input 3	DI (Dijital Input) (resetting totaliser)

Output 1	Pulse (0-100 Hz)
Output 2	4-20 mA Analog output
Output 3,4	Relay (2 relays) on-off output for Alarm or control
Output 5	Rs485 Modbus

Power excitation	24 Vdc for sensor

Display	2 rows 7-segment display

Power	100-240 Vac
