N1500G Large Process Indicator

57 mm Gösterge Yükseliği

4-20 mA, Röle ve Rs485 Modbus çıkışları

Sensörler için 24 Vdc Besleme çıkışı

Specifications

Versions	N1500G
Display	57 mm height 7 segment Display
Dimension	310 x 110 mm Depth : 37 mm Wall mounting
Input Types	Pt100, Thermocouple Temperature sensor 4-20 mA, 0-50 mV, 0-5 Vdc noon-Linear 4-20 mA, 0-50 mV, 0-5 Vdc (linearization point entries)
Functions	Offset Digital Filter Square Root Alarm functions
Output 1	Röle
Output 2	Röle
Output 3	4-20 mA
Output 4	Rs485 Modbus
Power Output for sensor	yes 24 Vdc (25 mA)
Power	100...240 Vac
Configuration	via keypad on device
Connection Diagram

Modbus Address Table Download

User Manual Download
