nSens Humidity Sensor for very high humidity applications
| Versions | nSens-HT-EIH | nSens-HT-ENF |
|---|---|---|
| Pictures |  |
|
| Humidity Range | 1...100 %RH | 1...100 %RH |
| Humidity Accuracy | ±0,6 %RH | ±1 %RH |
| Temperature Range | -20...+80 ºC | -20...+80 ºC |
| Temperature Accuracy | ±0,1 ºC | ±0,1 ºC |
| Working Temperature | -20...+80 ºC | -20...+80 ºC |
| Cable | sold seperately | sold seperately |
| Probe body | Plastic | Plastic |
| Probe dimension | 101x13 mm | 101x13 mm |
| Application | High Humidity and high accuracy | High Humidity at low temperature |
| Versions | nLink-Analog-IP | QuantaDat | nLink-Modbus |
|---|---|---|---|
| Pictures |  |
 |
 |
| Channel (Probe connection) |
One probe | 1 or 2 Probes | One probe |
| Display | No | Yes (4 row LCD) |
No |
| Analog Signal Outputs | 2 x 4-20 mA outputs | 4 x 4-20 mA outputs | No |
| Rs485 Modbus | -- | -- | Yes |
| Power | 24 Vdc | 24 Vdc | 5...18 Vdc |
