OT1200 HMI Scada Set

HMI Hardware Specifications

Versions	OT1207	OT1210	OT1212	OT1215
Pictures
Display Dimension	7"	10,1"	12,1"	15,6"
Resolution (pixel)	800x480	1280x800	1280x800	1920x1080
Touch Technology	Rezistive	Projective Capacitive (Multi Touch)	Projective Capacitive (Multi Touch)	Projective Capacitive (Multi Touch)
Ethernet	2 x Ethernet	2 x Ethernet	2 x Ethernet	2 x Ethernet
USB (2.0)	2 x USB	2 x USB	2 x USB	2 x USB
Working Temperature	0-60 ºC	0-60 ºC	0-60 ºC	0-60 ºC
Operating System	Linux Embedded	Linux Embedded	Linux Embedded	Linux Embedded

SCADA specifications

Versions	OT1207	OT1210	OT1212	OT1215
Pictures
Scada Licence (installed) (Developer)	Atvise Scada	Atvise Scada	Atvise Scada	Atvise Scada
CCD number	150	150	150	150
External Client	2 Web Client	2 Web Client	2 Web Client	2 Web Client
Automation Protocols	OPC UA (HA:Historical Access) Modbus TCP/IP MQTT Siemens S7 200/300/400/1200/1500 Mitsubishi Melsec Q/QL/FX5 Rockwell Compact/Control Logix BACnet KNX (Data Source : 3)	OPC UA (HA:Historical Access) Modbus TCP/IP MQTT Siemens S7 200/300/400/1200/1500 Mitsubishi Melsec Q/QL/FX5 Rockwell Compact/Control Logix BACnet KNX (Data Source : 3)	OPC UA (HA:Historical Access) Modbus TCP/IP MQTT Siemens S7 200/300/400/1200/1500 Mitsubishi Melsec Q/QL/FX5 Rockwell Compact/Control Logix BACnet KNX (Data Source : 3)	OPC UA (HA:Historical Access) Modbus TCP/IP MQTT Siemens S7 200/300/400/1200/1500 Mitsubishi Melsec Q/QL/FX5 Rockwell Compact/Control Logix BACnet KNX (Data Source : 3)
Other Connections	ODBC (SQL vb.) Web Service (ERP integrations) E-Mail Service	ODBC (SQL vb.) Web Service (ERP integrations) E-Mail Service	ODBC (SQL vb.) Web Service (ERP integrations) E-Mail Service	ODBC (SQL vb.) Web Service (ERP integrations) E-Mail Service

Download

Download

Atvise HMI Video Watch
