RHT Climate Duct Mount Humidity and Temperature Transmitter
-40...+100 ºC Probe measuring range and working temperature
2 x 4-20 mA and Rs485 Modbus outputs together
With or without display options
Probe lenght options : 150 mm, 250 mm and 400 mm
Stainless Steel probe
| Versions | RHT Climate-DM-150 | RHT Climate-DM-250 | RHT Climate-DM-400 |
|---|---|---|---|
| Pictures | |
|
|
| Probe Lenght | 150 mm | 250 mm | 400 mm |
| Versions | RHT Climate-DM-LCD-150 | RHT Climate-DM-LCD-250 | RHT Climate-DM-LCD-400 |
|---|---|---|---|
| Pictures | |
|
|
| Probe Lenghts | 150 mm | 250 mm | 400 mm |
| Humidity Range | 0-100 %RH | 0-100 %RH | 0-100 %RH |
|---|---|---|---|
| Humidity Accuracy | ±1,8 %RH | ±1,8 %RH | ±1,8 %RH |
| Temperature Range | -40...+100 ºC | -40...+100 ºC | -40...+100 ºC |
| Temperature Accuracy | ±0,2 ºC | ±0,2 ºC | ±0,2 ºC |
| Working Temperature |
-40...+100 ºC (probe) -40...+60 ºC (electronic) |
-40...+100 ºC (probe) -40...+60 ºC (electronic) |
-40...+100 ºC (probe) -40...+60 ºC (electronic) |
| Output 1 | 4-20 mA or 0-10 Vdc | 4-20 mA or 0-10 Vdc | 4-20 mA or 0-10 Vdc |
| Output 2 | 4-20 mA or 0-10 Vdc | 4-20 mA or 0-10 Vdc | 4-20 mA or 0-10 Vdc |
| Output 3 and 4 | DO (on-off) | DO (on-off) | DO (on-off) |
| Output 5 | Rs485 Modbus | Rs485 Modbus | Rs485 Modbus |
| Power | 12...30 Vdc | 12...30 Vdc | 12...30 Vdc |
| Setting | USB port (Free PC configuration software) |
USB port (Free PC configuration software) |
USB port (Free PC configuration software) |
| Calculations |
Dew Point Absolute Humidity Wet Bulb Temperature Frost Point |
Dew Point Absolute Humidity Wet Bulb Temperature Frost Point |
Dew Point Absolute Humidity Wet Bulb Temperature Frost Point |
|
|
|
|
|
| Protection Class |
Electronic Housing : IP65 Probe : IP30 |
Electronic Housing : IP65 Probe : IP30 |
Electronic Housing : IP65 Probe : IP30 |
| Housing dimension |
100 x 80 x 45 mm |
100 x 80 x 45 mm |
100 x 80 x 45 mm |
|
|
|
|
|
| Probe Lenght options |
150 mm |
250 mm | 400 mm |
