Wireless Humidity and Temperature Monitoring System

Humidity

Temperature

Humidity

Temperature

CO2

Humidity

Temperature

(External Probe)
(Prob Çalışma : -40...+125 ºC)

Temperature

(internal sensor)

Temperature

(One channel Pt1000 prob)

(-180...+250 ºC)

Temperature

(2 channels Pt1000 probes)

(-180...+250 ºC)

Humidity Accuracy : 2 %RH

Temperature Accuracy : 0,5 ºC

Internal Battey

(changeable)

low power consumtion

IP40

IP40

IP65

IP65

IP65

IP65

-20...+55 ºC

-20...+55 ºC

-20...+55 ºC

(Probe : -40...+125 ºC)

-20...+55 ºC

-20...+55 ºC

-20...+55 ºC

8 years
(5 min rate)

10 year or more
(15 min rate)

1 year
(5 min rate)

3 years
(15 min rate)

8 years
(5 min rate)

10 years or more
(15 min rate)

10 years
(5 min rate)

15 years
(15 min rate)

10 years
(5 min rate)

15 years
(15 min rate)

10 years
(5 min rate)

15 years
(15 min rate)

• Receiver unit collects data from wireless sensor nodes which listed above sensor table


• Wireless range between sensor nodes and receiver is arround 3,5 km


• Receiver has both Rs485 and Ethernet ports.


• Receiver can give out data as Modbus RTU, Modbus TCP/IP or Bacnet. please ask...


• Receiver unit works with external 12 Vdc or 24 Vdc power

• Repeater is using for extenting wireless range or increase quality of communication between wireless sensor nodes and Receiver unit.


• Plug and Play... no need to configuration


• Repeater needs external power as 12 Vdc or 24 Vdc.


• Repeater comes with small internal antenna which shown on picture.
