Novakon GW-01 Multi Protocol Gateway

Ürün Özellikleri

Model No :

GW-01

Port Özellikleri

2 x Ethernet

1 x Rs232

1 x Rs485

Otomasyon - PLC Protokolleri

Rs232 - Rs485 Portu için Protokoller		Ethernet Portu için Protokoller
Marka	Model	Marka	Model
Agilent	XGS-600 Gauge Controller	Allen Bradley	CompactLogix Ethernet
Allen Bradley	MicroLogix DF1 RS232		ControlLogix Ethernet
Allen Bradley	PLC5 DF1 CRC		Micro800 Ethernet
ANIMATICS	SmartMotor D-style RS232		MicroLogix Ethernet
CPC	cpcTorqueController	AwiseLink	IPP-Link
CTC	CTC Binary	BACnet	BACnet/IP
Delta	DVP v2	BECKHOFF	TwinCAT PLC: Free Tag Names
ESTIC	Handy2000 Type4	CODESYS	V3 Ethernet over ARTI
Facon	FB	Facon	FBs/FBe TCP
Facon	FBs/Fbe	Hitachi	EH/EHV Series TCP
Hitachi	MVH	Hitachi	EH/EHV Series UDP
Jector	Jector Controller	KEYENCE	KV-5000
KEYENCE	KV-1000		KV-8000/7500/7300
KEYENCE	KV-L20V Host Link		KV-NC1EP
Koyo	Direct DL Series	Mitsubishi	FX3U-ENET-ADP
Lust	LustBus ServoC/CDE Series		FX5U Ethernet
Misc	LedController		QJ71E71 Series
Misc	Scale		QJ71E71 Series(ASCII)
Mitsubishi	AJ71	Modbus	Modbus RTU Slave over TCP
	AJ71 for AnA/AnU		Modbus TCP Slave
	AJ71 Format4		Modbus RTU Slave over TCP (Not Optimized)
	FR-A700		Modbus TCP Slave (Not Optimized)
	FX2N Series	Omron	FINS TCP
	FX3U Series	Omron	NJ/NX EtherNet/IP
	FX3U Series 232/485BD	Panasonic	FP TCP
	FX/FX2N Series 232/485BD	Siemens	ISO on TCP
	Q00UJ	Toshiba	TMFCD91A
	QJ71C24 Series	Vigor	VS TCP
	FX Series	Vigor	VS UDP
	Q Series	YASKAWA	MP2000 Series Extension
	Servo Amplifier MR-J4-A		MP3000 Series Extension
MKS	MKS MC700		MP Series Memobus
Modbus	Modbus ASCII Slave	YOKOGAWA	FA-M3 Series TCP
	Modbus RTU Slave
	Modbus ASCII Slave (Not Optimized)
	Modbus RTU Slave (Not Optimized)
	Teco Servo
Omron	CS/CJ
Omron	C (TPM1A, CP1E, CP1L)
Panasonic	FP Series
PBA Systems	MaxTune VarCom with checksum
RGB	RGB LED
Siemens	Simatic S7-200 PPI
TECO	TP03
TECO	AC Servo TSDA Series
Vigor	VB/VH/M Series
Vigor	VS Series
Yamateke	DCP30
	DMC50 v3
	NX-D15/25
	SDC35

Teslim Etme Protokolleri

(OPC UA Client ve OPC UA Server HA)
MQTT Client ve Dahili MQTT Broker
Dahili MySQL'inden anlık verilerin ve kayıtların alınabilmesi veya uzaktaki MS SQL veya MySQL'e anlık verilerin yazılması
