LoraWan Wireless measuring device Battery Operated and Power Excitation Voltage output for sensors
| Model Number | ADS-270-82 |
|---|---|
| Picture |  |
| Decription |
ADS 270 is a functional wireless measuring device that it can work with one battery while providing a power source t the sensors which connected to this unit. Data reads from Rs485 Modbus and SDI12 sensors. It is designed to work at harsh conditions. |
| Analog Input |
1 ch. 0-1 Vdc 12 Bit resolution |
| Dijital Input |
1 Ch. 0-30 Vdc trigger Counter function (0...40 Hz) |
| Modbus Reading |
1 x Rs485 Port Modbus RTU Protokol (as Master) Reads 8 Modbus Channels |
| SDI12 Reading |
1 x SDI12 Port supports t read up to 8 SDI12 channels |
| Power Supply Output |
12 Vdc (max 250 mA) or 5 Vdc (max 200 mA) (selectable) |
| Measuring and Data Send Rate |
1 min or more (selectable) |
| Wireless Technology | LoraWan |
| Distance | It depends accrding used LoraWan Gateway. There are products which supports from3 km to 20 km distance. |
| Worrking Temperature | -40...+65 ºC |
| Prrotection |
IP66 (IP68 is options) |
| Configuration | By PC Configuration Software, USB connection to the PC. |
