Temperature Transmitters - Converters

Head Type Temperature Transmitter
Din Rail Temperature Transmitter

Versions

Versions	TxBlock-USB	TxRail-USB
Pictures
Sensor Input options	Universal Input : Pt100, Pt1000 Thermocouple (J, K, T, N, R, S, B, E) NTC 0...50 mV	Universal Input : Pt100, Pt1000 Thermocouple (J, K, T, N, R, S, B, E) NTC 0...50 mV
Output Signal	4-20 mA	4-20 mA or 0-10 Vdc (selectable)
Power	10...30 Vdc (2 wire)	for 4-20 mA : 10...30 Vdc (2 wire) for 0-10 Vdc : 12...35 Vdc
Configuration	USB port (Micro B) free software	USB port (Micro B) free software
Working Temperature	-40...+85 ºC	-40...+85 ºC
Dimension	43,5 x 20,5 mm	114 x 100 x 12,5 mm

Rail Mount User Manual Download

Rail Mount Data Sheet Download

Head Mount User Manual Download

Head Mount Data Sheet Download

TxRail-USB Rail Mount Transmitter Video Watch

TxBlock-USB Head Transmitter Video Watch
