LoraWan on-off Status Monitor and Pulse Meter Wireless Measuring Device

TX-CONTACT

TX-PULSE

TX-PULSE ATEX

Modeller

Versions	TX-CONTACT	TX-PULSE	TX-PULSE-ATEX
Pictures
Parameters	Dry Contact Input (Measurement of on-off signal) 2 Channels	Pulse and Dry Contact Input (1 ch Pulse counting - 1 ch on-off state measurement) 2 channels	Pulse and Dry Contact Input (1 ch Pulse counting - 1 ch on-off state measurement) 2 channels ATEX Zone 0
Pulse Channel	-	10 Hz	10 Hz
Power	Internal Battery (changeable) (very low power consumption)
Protection Class	IP65	IP65	IP65
Working Temperature	-20...+55 ºC	-20...+55 ºC	-20...+55 ºC
Estimated Battery Lifetime	10 year or more (at every 15 minutes measurement rate)	10 year or more (at every 15 minutes measurement rate)	10 year or more (at every 15 minutes measurement rate)

Download

Watch

Soru 1

Cevap 1

Demo software downloads will be activated by filling out the form.

Now you can download the following software suitable for you. After clicking the button, the download link of the software will be sent to your e-mail address.
